Page 51
WATER PUMP & CHEMICAL PUMP
86037400 08/21/07
5-12
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86190540
12-800029 1
PLUG,
1/4T
BR
2
86273710
140645
4
SCR, 1/4-20 X 3/8, SER FLNG
3
86180340 12-800031
1
ELL, 1/4P X 1/4T BR
4
86190670 41-809153
1
PMP, WTR CAT 3CP1140
5 86175110
44-802315 1
BELT,
AX40
6
86282770
51372
1
LOOM, 1/4, HIGH TEMP 10”
7
86265780 31-900185
1
CONN, BULLET M (.156)
8
86177510
790613
1
CLUTCH, ELE, WTR PMP CAT 3CP
9
86249610
790610
1
BRKT, CLUTCH, WTR PMP, 3CP CAT
10
86278830 02-000143
2
WASHER, 5/16 FLAT PLTD
11
86276130
70601
2
SCR, 5/16-18 X 2.75 HHCS GR5
12
86043770
790544
1
ASSY, PMP ADJ BRKT
13
86241860
48099
1
KEY, .20X.20X1.45, 3CP CAT
14
86005750
57113
2
NUT, 5/16-18 HEX NYLOCK
15
86190520 11-800224
1
PLUG, 3/8 SOCHD BR
16
86191780 52-809123
1
RETAIN, VALVE SPRING
17
86180360 12-800040
1
ELL, 1/8P X 1/4T BR
18
86179920
790605
1
EL, 90DEG 1/8 X 5/16HB
19
86176990 03-000065
1
CLAMP, HOSE #4 SST
20
86279820
87240
1
WSHR, .328 ID X 1.00 OD X .119 ZNC
21
86191440
791173
1
PUMP, CHEM, PULSE, GP
1000151479 WAS 41-809158
22
86173750 52-809125
1
ADPT, CAT CHEM PMP
23
86273700
140644
1
SCR, 5/16-18 X 1, SOC, ZNC
24
86177020 03-000113
1
CLAMP, HOSE #12 SST
25
86181370 12-800278
1
FTTG, BRB 1/2P X 3/4H BR
26
86180230 11-800299
1
ELL, STREET 1/2 45 DEG
27
86180410 12-800225
1
ELL, 3/8P X 1/2T BR
28
86194630
65250
1
PULSE PUMP, TOP COVER INLET
1000151479 WAS 52-502053
29
86179550 42-809047
1
DIAPHRAGM, CHEM PUMP
30 86249220 65252 1 PLASTIC
DISC
1000151479 WAS 42-809264
31
86173440 43-810105
1
O-RING, 1-58 ID X 1-3/4 OD VITON
1000151479
32
86195100
65245
1
VALVE CAP, 303 SST, INPUT
1000151479 WAS 16-808237
33
86195110
65247
2
VALVE KIT, ASM, CHEM, PULSE PUMP 1000151479 WAS 42-809265
34
86189290
65249
2
O-RING, DURO,. 862ID X .103CS
1000151479 WAS 43-810079
35
86191340
65253
1
PULSE PUMP, BODY
1000151479 WAS 52-502052
36
86006740
70266
3
SCR, 3/8-16 X 1” HHCS GR 5 PLTD
37
86010790
87163
4
WASHER, 3/8 SPLIT LOCK PLTD
38
86279510
87171
3
WASHER, 3/8 FLAT
39
86177320 03-000249
1
CLMP, CABL 1/4ID 3/8BLT
40
86273420 00-000336
1
SCR, CAP 3/8-16 X 3 ALL THD
41
86192920
65246
1
SPACER RING, 303 SST
1000151479
42
86195120
65248
1
VALVE CAP, 303 SST, OUTPUT
1000151479 WAS 16-808237
