WAND- TRI JET-OPTIONAL
86037400 02/16/07
5-36
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL
NO. FROM
NOTES:
-
86285520
89233
-
WAND, TJW (9502) PC
COMPLETE
-
86285510
89232
-
WAND, TJW, (95015) CUBXL
COMPLETE
-
86285530
89234
-
WAND, TJW, (9503) PC
COMPLETE
1
86005580
56012
1 NIPPLE, 1/4 FPT QD
2
86177860
17-803010
1 CONN, 1/4P X 11/16-16M
3
86195570
17-803006 2
WASHER,
NYLON
4
86193490
14-806512
1 STRAINER, JET 50MESH
5
86177870
17-803036
1 CONN, 1/4FP,11/16-16R BR
6
86247680
56015
1 NIPPLE, 1/4 HEX
7
86280020
09-805359
1 SLEEVE, WD HDL 9.5
8
86194650
52-501619
1 TRIGGER, WD VLV
9
86192030
00-000317
3 SCR, CAP 10-32X 1-1/4 SOCH
10
86270990
57090
3 NUT, 10-32 HEX NYLOCK SS
11
86174120
61-950496 1
ASSY,
EXTRCTR
VLV
12
86177650
12-800060
1 CONN, 1/4P X 1/4T BR
13
86183970
10-805253
1 HOSE, 3/16X49 (1/8P X 1/4FT)
14
86265730
04-000053
3 TIE, CABLE 8” WHT
15
86273310
00-000282
1 SCR, CAP 1/4-20 X 1-1/4 SOC
16
86198160
52-501569
1 HOLD DOWN, WD HDL
17
86182840
791150
1 BODY, WD HDL
18
OPEN
- 1
-
19
86194410
17-803002
3 TIP, SPRY 9502X1/8P SST
89233
19A
86194400
17-803001
3 TIP, SPRY 9501X1/8P SST
89232
19B
86194520
17-803046
3 TIP, SPRY 9503X1/8P SST
89234
20
86274290
70162
2 SCR, 10-32 X 3/8 PPHMS SS
21
86279470
87165
2 WASHER, #10 SPLIT LOCK
22
86270800
57014
2 NUT, 10-32 HEX SS
23
86187700
56-501739
1 MANIFOLD, WD TRI-JET
24
86190180
11-800206
2 PLUG, 1/8 SOCHD BR
25
86183160
16-808229 1
HOLDER, VLV STEM-EXTRCTR
VL
26
86189520
43-810063
1 O-RING, .551 ID .691 OD
27
86192410
16-808228
1 SEAT, EXTRCTR VLV
28
86193360
16-808189
1 STEM, EXTRCT VLV
29
86174500
43-810064
1 BACK-UP, .250DIA
30
86189510
43-810062
1 O-RING, .114ID .254OD
31
86193200
16-808190
1 SPRING, EXTRCTR VLV
32
86179020
52-501590
1 BODY, EXTRCTR VLV
-
86179020
48-941166
-
DECAL, WD HD
NOT SHOWN
-
86186160
66-808169
-
KIT, REP-WD VLV
NOT
SHOWN
INCLUDES PARTS 25-
27 & 29-31
