HEAT EXCHANGER
86037400 02/16/07
5-16
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86056820 790714 3 SPACER, ENG SUPPORT
2 86278830 02-000143 9 WASHER, 5/16 FLAT PLTD
3 86192110 790721 3 SCR, 5/16-18 X 4.0 HHMS PLATED
4 86274750 70270 26 SCR, 1/4-20 X 3/4 HHCS PLTD
5 86010780 87162 24 WASHER, 1/4 SPLIT LOCK PLTD
6 86270330 02-000066 18 FLATWASHER, 1/4
7 86029430 790707 1 MUFFLER, VAC W/EXH TUBE
8 86181810 43-807080 1 GASKET, VAC HE INLET
9 86175920 11-800118 1 BUSH, 3/8 X 1/8 BR
10 86192490 34-903019 1 SENDER, TEMP 140-320 DEG
11 86043150 790388 2 ASSEMBLY, HEATER CORE SS
12 86047250 790668 1 COVER, SST CORE VAC HE
13 86059020 790708 1 TUBE, SILENCER/EXH MNFLD
14 86177700 12-800282 2 CONN, 3/8P X 1/2T BR
15 86180220 11-800276 3 ELL, 3/8 BR
16 86181400 12-800345 1 FTTG, BRB 3/8P X 5/8H BR
17 86182190 36238 6 GRONR, 1/2ID X 1-1/4OD 1/8G 5/16W
18 86190520 11-800224 6 PLUG, 3/8 SOCHD BR
19 86187210 790038 3 MANIFOLD, HEATER CORE
20 86047260 790680 1 COVER, COPPER CORE VAC HE
21 OPEN - - -
22 86030280 790801 1 ASSY, HEATER CORE COPPER INCLUDES 17 & 20
23 86189730 790423 6 PAD, REAR VAC HTR CORE
24 86181850 790050 3 GASKET, VAC HE CVR
25 86005650 57031 3 NUT, 5/16-18 HEX
26 86279130 87083 6 WASHER, 5/16 SPLIT LOCK PLTD
27 86273440 00-000340 3 SCR, MACH 5/16-18 X 1” GR8
28 86049190 790671 1 HSG, VAC HE
29 86177000 03-000086 1 CLAMP, MFLR 1-1/4
30 86181330 12-800161 1 FTTG, BRB 3/8P X 1/2H BR
31 86010740 87090 6 WASHER, 1/4 ID X 3/4 OD PLTD
