Instruction Manual SVS1 Series
1
1. GENERAL INFORMATION
1.1. Conventions used in the manual
This manual has been developed to provide clear and precise instructions on how to use the SVS1
system.
For more detailed information on the algorithms and techniques referenced in the manual, please find
symbols such as (
) present throughout the text which refer to Chap.14 - TUTORIAL.
Boxed text provides definitions to ensure better understanding of the specific topic.
Examples are printed in italics.
This refers to particularily interesting information.
For other significant terms, please refer to the GLOSSARY in Chapter 15.
1.2. General description
SVS1 by Datasensor S.p.A. is a vision sensor (machine vision
) which is easy to use and has
advanced inspection functions which allow it to be implemented in many fields (quality control on
production lines or automatic material handling are just a few examples).
It basically works by comparing the digital image (
) acquired in a precise moment ("target image")
and a previously acquired reference image ("reference image").
Once the SVS1 has been configured (using the VSC), it can function in "stand-alone" mode, that is
completely automatic.
1.3. Available models
Description
Item
Number
Model
Sensor Lens
VSC
configurator
Connection
cable
Power
cable
959941000 SVS1-08-DC-K 8mm
959941010 SVS1-06-DC-S 6mm
959941020 SVS1-08-DC-S 8mm
959941030 SVS1-12-DC-S 12mm
959941040 SVS1-VSC
