Operation
TPS1200
65
4.3.4
LED Indicators on Clip-On-Housings
LED Indicators
Description
Each clip-on-housing for a radio or a digital cellular phone has Light Emitting Diode
indicators. They indicate the basic device status.
Diagram of the LED Indicators
a) Power LED
b) Signal strength LED
c) Data transfer LED
d) Warning LED,
available for Satelline 3AS
TPS12_211
a b c d
