Technical Data TPS1200 183
8.7.3 SmartAntenna Technical Data
Description and
use The SmartAntenna is selected for use based upon the application. The table gives
a description and the intended use of the SmartAntenna.
Dimensions
Connector • 8 pin LEMO-1 socket to connect antenna cable (only applicable when SmartAn-
tenna is used independently on a pole with RX1250).
• Special clip-on interface for connecting SmartAntenna to SmartAntenna Adapter
on a TPS1200 instrument.
Mounting 5/8" Whitworth
Weight 1.1 kg including internal battery GEB211
Type Description Use
ATX1230 GG/
ATX1230 L1/L2 SmartTrack+/SmartTrack
antenna with built in ground-
plane. With RX1250 or TPS1200.
Height: 0.890 m
Diameter: 0.186 m
