LEICA TPS1200 - Manual (Page 143)

Safety Directions TPS1200 143
ƽ
Warning For safety aspects direct intrabeam viewing should always be considered as
hazardous.
Precautions:
Do not stare into the beam or direct it towards other people unnecessarily. These
measures are also valid for the reflected beam.
ƽ
Warning Looking directly into the reflected laser beam could be dangerous to the eyes when
the laser beam is aimed at areas that reflect like a mirror or emit reflections unex-
pectedly, for example prisms, mirrors, metallic surfaces or windows.
Precautions:
Do not aim at areas that are essentially reflective, such as a mirror, or which could
emit unwanted reflections.
Description R100 R300
Maximum average radiant power 4.75 mW ± 5% 4.75 mW ± 5%
Maximum peak radiant power 59 mW ± 5% 59 mW ± 5%
Pulse duration 800 ps 800 ps
Pulse repetition frequency 100 MHz 100 MHz - 150 MHz
Beam divergence 0.15 mrad x 0.35 mrad 0.15 mrad x 0.5 mrad
