110 TPS1200 Check & Adjust
Inspecting the
direction of the
beam step-by-step
The following table explains the most common settings.
Step Description
1. Set up the provided target plate between 5 m and 20 m with the grey
reflective side facing the instrument.
2. Move the telescope to face II.
3. Switch on the red laser beam by activating the laser pointer function.
SHIFT F11 to access CONFIGURE Lights, Display, Beeps, Text and
then select the Lights page.
TPS12_36
