Technical Data TPS1200 199
Control unit
Instrument Ports
Display: 1/4 VGA (320 x 240 pixels), monochrome, graphics
capable LCD, illumination, optional touch screen
Keyboard: 34 keys
including 12 function keys and 12 alphanumeric keys,
illumination
Angle Display: 360°’", 360° decimal, 400 gon, 6400 mil, V %
Distance Display: m, ft int, ft us, ft int inch, ft us inch
Position: In both faces, face two is optional
Touch screen if fitted: Toughened film on glass
Port Name Description
Port 1 Port 1 • 5 pin LEMO-0 for power, communication, data transfer.
• This port is located at the base of the instrument.
Port 2 Handle • Hotshoe connection for RadioHandle with RCS and
SmartAntenna Adapter with SmartStation.
• This port is located on top of Communication side cover.
Port 3 BT • Bluetooth module for communication.
• This port is housed within Communication side cover.
