Check & Adjust
TPS1200
101
5.4
Tilting Axis Adjustment (a)
Description
This adjustment procedure determines the following instrument error:
Determination of
tilting axis error
step-by-step
The following table explains the most common settings.
a
Tilting axis error
Step
Description
)
The Hz collimation error (c) has to be determined before starting this
procedure.
1.
Main Menu: Tools...\Check & Adjust...
2.
TOOLS Check & Adjust Menu
Select the option: Tilting Axis (a)
