82
www.honeywell.com/sensing
GSE EN 50047 Compatible
Safety 3 Conduit Metal
Standard
conduit
thread
60 /
2.37
4 /
0.16
52 /
2.05
57 /
2.24
65 /
2.56
13,75 /
0.54
2,5 /
0.1
R 2,15 /
0.08
3 /
0.12
20 /
0.79
22 /
0.87
40 /
1.57
42 /
1.65
23,8 /
0.94
ш 23 /
ш 0.9
30 /
1.18
12 /
0.47
12,5 /
0.49
24,75 /
0.97
Mechanical life: up to 1 million
Sealing: IP 66, NEMA/UL 1, 4, 12, 13
Operating temperature: -25 °C to 85 °C
(-13 °F to 185 °F)
Approvals: IEC/EN 60947-5-1
AC15 A300
DC13 Q300
UL, CSA, BG
ACTUATED SWITCHES
Rotated 90° to the left
from center
70 /
2.76
45 /
1.77
104 /
4.09
CONTACT CONDUIT REFERENCE
2NC/2NO, BBM ½ in NPT GSEA44S1
3NC/1NO, BBM ½ in NPT GSEA46S1
4NC, low energy 20 mm GSEC41S1
Rotated 90° either direction from
center
12,5 /
0.49
24,8 /
0.97
2 /
0.08
11,5 /
0.45
5,1 /
0.20
45 /
1.77
70 /
2.76
28 /
90 min. 90 min.
CONTACT CONDUIT REFERENCE
2NC/2NO, BBM ½ in NPT GSEA44S2
Rotated 90° to the right
from center
180 MIN
CONTACT CONDUIT REFERENCE
2NC/2NO, BBM ½ in NPT GSEA44S3
SAFETY SWITCHES
