ULTRASONIC DISTANCE SENSORS
942 Series
2 Piece
30 mm diameter sensor with
RS232 Interface
Voltage and current output
2 switching RS232 interface
Max. sensing distance: 1500 mm
Min. sensing distance: 150 mm
Beam angle: 10°
Repeatability: 0,2 % or ±1 mm
Switching frequency: 5 to 8 Hz
Response time: 120 ms
Supply voltage: 19 to 30 V
Sealing: IP65
Housing: M30 stainless steel
REFERENCE
Complete sensor: 942-M3A-2D-1G1-220S
941 Series
Limit switch style
Max. sensing distance: 1500 mm
Min. sensing distance (adjustable): 200 mm
Beam angle: 10°
Repeatability: ±1 mm
Supply voltage: 18 to 50 V
Sealing: IP65
Housing: Zinc die-cast, sea water resistant paint finish
OPTIONS
Analogue voltage output, 0-10 V
Response time: 150 ms
REFERENCE
941-C2V-2E-1C0
Switching
2 adjustable switching outputs PNP NO
Switching frequency: 10 Hz
REFERENCE
941-C2V-2E-001
