Appendix D : IPSec Tunnel Examples
VPN Configuration – Examples
Tunnel to HotBrick Unit
The HotBrick units in the following example use registered IP addresses. You have to replace these
addresses with IP addresses that are available to you. These settings are only possible if you have a static IP
address available on one or both of your WAN ports.
This example takes a tunnel between a VPN 800/8 F and a LB-2 VPN. This example applies to the
HotBrick 401VPN X2, LB-2 VPN and 800/8 F series, you can use either unit at both sides. You can use the IP
addresses from the network diagram above.
This type of tunnel is named a LAN to LAN IPSec tunnels.
