Spanning-Tree Operation
802.1D Spanning-Tree Protocol (STP)
STP is enabled.
Port A1 and Trk1 are
now configured for
fast-uplink STP.
Figure 5-18. Example of STP Enabled with Two Redundant Links Configured for
Fast-Uplink STP
5. Press [S] (for Save ) to save the configuration changes to flash (non-volatile)
memory.
To View Fast-Uplink STP Status. Continuing from figures 5-17 and 5-18 in
the preceding procedure, this task uses the same screen that you would use
to view STP status for other operating modes.
1. From the Main Menu, select:
1. Status and Counters …
7. Spanning Tree Information
5-39
