16. Specification
Tuner & Channel
Input Connector IEC 169-2 female
Frequency Range 47MHz to 862MHz
Input Impedance 75
Signal Level -13 to +15dBmV
Demodulation QAM
Input Symbol Rate 1.5-7Ms/s
Constellation 16-QAM, 32-QAM, 64-QAM, 128-QAM, 256-QAM
MPEG Transport Stream A/V Decoding
Transport Stream MPEG-2 ISO/IEC 13818
Profile Level MPEG2 MP@ML
Input Rate 15 Mbit/s Max
Aspect Ratio 4:3, 16:9
Video Resolution 720x576, 720x480
Audio Decoding MPEG/MusiCam Layer I & II
Audio Mode Single /Dual mono/ Stereo /Joint stereo
A/V & Data In/Out
Video RCA/TV SCART/VCR SCART Video Output (CVBS, S-Video, RGB)
Audio L/R RCA/TV SCART/VCR SCART Volume and Mute Control
(Resolution:20bits DAC, MAX. 2Vrms)
RS-232C 9 PIN Male Socket
S/PDIF Digital Audio Output, Fiber-Optic (Resolution: 20bits)
USB USB 2.0 Device (connectable to the USB of PC)
Power Supply
Input Voltage 90-250V a.c., 50/60Hz
Type Switching Mode Power Supply (SMPS)
Power Consumption Operation - Max 23W
Standby - Max 14W
Protection Separate internal fuse & Lightning protection
Physical Specification
Size 380 mm*78 mm*281 mm
Weight (Net) 3.7kg
Operating Temperature 0 to +45
Storage Temperature -10 to +70
