Installation
Document 800-00919 Rev F 25
02/08
Note The audio input is from an amplified source. The DVR does not
have amplified audio output, so you will need a speaker with an
amplifier.
Setting Unit for CVBS or VGA Output
Set the switch to CVBS or VGA for monitor output. Select CVBS for spot monitor, and
select VGA for RGB monitor.
Figure 2-5 CVBS/VGA Switch
Note The DVR might not support some LCD monitors or some
monitors don't support Multi Sync.
Note You cannot use spot monitor output and VGA output at the same
time.
Note Set the CVBS or VGA selector switch before turning on the DVR.
You cannot change the setting while the unit is running.
Connecting the Monitor
Connecting the Spot Monitor
Connect the SPOT monitor to the Video Out connector.
