Specifications
Document 800-00919
Rev F
129
02/08
F
Specifications
Video Specifications
Signal Format
NTSC or PAL (auto detect)
Video Input
Composite: 4 looping inputs, 1 Vp-p,
auto-terminating, 75 Ohms
Monitor Outputs
Composite: One (BNC), 1 Vp-p, 75 Ohms
Analog RGB: One (VGA)
•
NTSC: 30.8kHz (horizontal frequency) / 60Hz
(vertical frequency)
•
PAL: 30.8kHz (horizontal frequency) / 50Hz
(vertical frequency)
Video Resolution
720x480 (NTSC), 720x576 (PAL)
Playback/Record Speed
(images per second)
Standard: 120ips (NTSC), 100ips (PAL)
High: 60ips (NTSC), 50ips (PAL)
Inputs/Outputs
Alarm Input
4 TTL, NC/NO programmable, 4.3V threshold
Alarm Output
2 relay out, terminal block, NC & NO, 0.5A @
125VAC, 1A @ 30VDC
Alarm Reset Input
1 TTL, terminal block
Internal Buzzer
80dB at 10cm
Network Connectivity
10/100 Base Ethernet, RS-232C for external
modem
Audio Input
1 line in
Audio Output
1 line
