Honeywell HRSD4 - Manual (Page 130)

Specifications
130
Specifications are subject to change without notice.
Connectors
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC
Monitor Output Composite: 1 BNC
Analog RGB: 1 (VGA)
Audio In 1 RCA connector
Audio Out 1 RCA connector
Alarms Terminal block
Alarm Reset In Terminal block
Ethernet Port RJ-45
RS-232C Serial Port DB9 (P)
USB Port 1 on front panel (1.1)
IR Port 1 Remote Control
Storage
Primary Storage EIDE hard disk drive (1)
Clip Copy USB hard disk drive, CD-RW drive or Flash Memory
General
Dimensions (W x H x D)
(including BNC plug) 13.4” x 1.8” x 12.2” (340mm x 46.5mm x 310mm)
Unit Weight 7.1 lbs. (3.2kg)
Shipping Weight 9.7 lbs. (4.4kg)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 100-240V~, 50/60Hz, 0.6A
Approval FCC, CE, UL
