Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2
Plug the power adapter connector into the DC-IN on the rear panel of
the TV.
3
Plug the three-pronged plug at the other end of the power cord into a
power outlet.
DC-IN
LINE OUT
AV 2
ANT
R
L
VIDEO
S-VIDEO
DC-IN
LINE OUT
AV 2
ANT
R
L
VIDEO
S-VIDEO
AV1
AV1
Power cord
DC-IN
Power outlet
Power adapter
Three-pronged
plug
