3 - 7
Scanner LED Sequences and Meaning
Base/Access Point LED Sequences and Meaning
The base contains a red LED and the Access Point has a blue LED that
indicate the status of the unit and verifies its communication with the host
system. The base also has a green LED that indicates scanner battery
charge condition.
LED Indication Beeper Indication Cause
Normal Operation
Red Flash
None Battery low
Green Flash 1 beep Successful
communication or linking
Red, blinking Razz or error tone Failed communication
Menu Operation
Green Flash
2 beeps Successful menu change
Red, blinking Razz or error tone Unsuccessful menu
change
Red or Blue LED - Host Communication
Communication Condition Red or Blue LED
USB suspend Off
Power on, system idle On continuously
Receiving data Short blinks in multiple pulses. Occurs
while transferring data to/from the RF
module or the Host port.
Green LED - Scanner Battery
(base only, does not apply to Access Point)
Charge Condition Green LED
Battery not detected or charge
suspended Off
Pre-charge and charging Slow flash, 1 second on, 1 second off
Charge complete On continuously
Charge Error Fast flash, 300 mSec on, 300 mSec off
