Honeywell XENON 1902 - Manual (Page 283)

12 - 3
CCB01-010BT Charge Base Product
Specifications
Parameter Specification
Dimensions (Typical):
Height 3.2 inches (8.128cm)
Length 5.19 inches (13.183cm)
Width 3.98 inches (10.109cm)
Weight 6.3 oz (179g)
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port 500mA
Aux Power Port 1A
Charge Time 5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 33 ft. (10 m) typical
Data Rate Up to 1 MBps
Temperature Ranges:
Operating 32 ° F to +122° F (0° C to +50° C)
Battery Charge 41 ° F to +104° F (5° C to +40° C)
Storage -40 ° F to +158° F (-40° C to +70° C)
Humidity Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 3.28 feet
(1 m) to concrete
Vibration 5G Peak from 22Hz to 300Hz
ESD Sensitivity
Up to 15kV direct air
Up to 8 kV indirect coupling plane
