Setting Up the PC

5

Setting Up the PC

Follow the steps in the setup poster to set up the PC,
and then read the topics in this section to find out
more about the location of components and
connectors on your PC, and to find out about some
setup alternatives.

Most of the hardware devices such as the monitor,
keyboard, printer, and mouse can be connected at
the back of the PC. Some peripheral devices, such
as a digital video camera, can be plugged into the
connectors on the back or the front of the PC.

HP Media Center PC Front Connectors

n

Location, availability,
and number of
connectors may vary.

Connector

Icon/label

Description and function

S-Video 2

Secondary S-video connector to connect your VCR, video
camera, or other analog source to the PC

Composite

Video 2

Secondary Composite video connector to connect VCR, video
camera, or other analog source to the PC

L Audio 2

Secondary Left audio input connector

R Audio 2

Seondary Right audio input connector

Headphones Out

Microphone In

Universal Serial Bus (USB 2.0) for mouse, keyboard, digital
cameras, or other devices with USB connectors

FireWire

®

(IEEE 1394) connector for video cameras and other

high-speed devices

1394
