Htc corporation – HTC SAPPHIRE SM-TP008-1125 User Manual
Page 28
2/10/2009 9:51:19 PM
HTCUSA-200015
Doc. No.
DOC-00051810 REV.
Issued Date 2008/12/29
.
Revised Date
2009/01/14
AX02
Doc. Title
Sapphire Service Manual
Page
28 of 91
HTC CONFIDENTIAL
SM-TP008-1125
HTC Corporation.
16. Attach the Volume FPC
to the Chassis
17.
Combine Main FPC
upper board as show
18. Fasten the screws at the
location indicated
Screw:
72H01266-01M
Torque : 1.0+-0.1kgf-c
