z Install the SIM card
1. Make sure your device is turned off.
2. Press the back cover latch down and gently slide the back cover towards yourself. Once the back
cover pops out, remove it by lifting it up from the bottom end.
3. If you have installed the battery, remove it by lifting it up from the bottom end.
4. Insert the SIM card into the slot with its gold contacts facing down and its cut-off corner facing toward
outside of the slot.
5. Install the battery by inserting it with its exposed copper part aligned with the protruding copper
conductor on the upper right side of the battery compartment. Insert the upper part of the battery first,
then gently push the battery into place.
6. Replace the back cover by gently sliding back in until it snaps in place.
