Dolphin® 9500 Series User’s Guide 2 - 5
Image Engine Options and Specifications
Dolphin 9500/9550 Terminals
Dolphin 9500/9550 terminals can be equipped with one of the following image engines:
Note: The IT4300SR image engine contains a high-visibility aimer that projects aiming brackets around the bar code or image
preview for maximum viewability and aiming. For details, see IT4300SF and IT4300SR with High-Vis Aiming Pattern on
page 4-5 and page 4-6 .
For more information, see Using the Image Engine on page 4-4.
Dolphin 9501/9551 Terminals
Dolphin 9501/9551 terminals can be equipped with one of three laser engines. For details, see Laser Engine Specifications on
page 11-1.
IT4100 Standard Range (IT4100SR)
IT4300 Standard Range (IT4300SR)
Code 8 mil Linear 10 mil PDF417 13 mil UPC 15 mil PDF417 15 mil Data Matrix 35 mil MaxiCode
Working Range (.020cm) (.025cm) (.033cm) (.038cm) (.038cm) (.089cm)
Near 3.4 in. (8.6cm) 3 in. (7.6cm) 2.4 in. (6.1cm) 3.4 in. (8.6cm) 3.6 in. (9.1cm) 1.9 in. (4.8cm)
Far 7.5 in. (19cm) 8.9 in. (22.6cm) 12.4 in. (31.5cm) 11.1 in. (28.2cm) 6.4 in. (16.2cm) 12.9 in. (32.7cm)
IT4100 Smart Focus (IT4100SF)
IT4300 Smart Focus (IT4300SF)
Code 6.6 mil PDF417 7.5 mil Linear 10 mil Linear 13 mil UPC 10 mil PDF417 15 mil Data Matrix
Working Range (.017cm) (.019cm) (.025cm) (.033cm) (.025cm) (.038cm)
Near 2.7 in. (6.8cm) 2.4 in. (6.1cm) 2.1 in. (5.3cm) 2.2 in. (5.6cm) 2.1 in. (5.3cm) 2.2 in. (5.6cm)
Far 5.9 in. (14.9cm) 6.4 in. (16.2cm) 7.5 in. (19cm) 8.8 in. (22.3cm) 7.5 in. (19cm) 5.9 in. (14.9cm)
IT4100 High Density (IT4100HD)
Code 4 mil Linear 5 mil Linear 6.6 mil PDF417 9 mil Data Matrix 10 mil Data Matrix 10 mil QR
Working Range (.010cm) (.013cm) (.017cm) (.023cm) (.025cm) (.025cm)
Near 2.5 in. (6.4cm) 2.3 in. (5.8cm) 2 in. (5.1cm) 2.7 in. (6.8cm) 2.4 in. (6.1cm) 2.3 in. (5.8cm)
Far 3.5 in. (8.8cm) 4.2 in. (10.6cm) 4.9 in. (12.4cm) 3.7 in. (9.4cm) 4 in. (10.1cm) 3.4 in. (8.6cm)
