11 - 6
Dolphin® 9500 Series User’s Guide
Dolphin 9551 Hardware
The Dolphin 9551 terminal features the same integrated pistol grip as the Dolphin 9550 for secure and versatile handling in scan-
intensive applications. The front end of the bottom housing accommodates the laser engine.
Side Panel
The following graphic shows the left, side panel of the Dolphin 9551.
Just like the Dolphin 9550, the stylus is stored in the pistol-grip handle.
Laser
Engine
