38 Getting Started Guide
Using the Audio Wizard in the Sound Effect Manager
The Sound Effect Manager Audio Wizard can help you connect front-panel audio.
To use the Audio Wizard:
1 Turn on the PC.
2 Click Start on the taskbar.
3 Choose Control Panel.
4 Click Sounds, then Speech and Audio Devices (or Sounds and Audio
Devices).
5 Click Sound Effect Manager. The window opens.
6 Click Audio Wizard. A window opens that shows the connector panel on the
front of the PC.
7 Place a check in the Enable jack detection check box to enable the wizard.
8 Connect the speaker system audio cable plugs into the connectors on the front
of your PC. The panel display highlights a cable that is properly inserted in a
connector.
9 Close the window.
Retasking front-panel connectors with Sound Effect
Manager
With the Audio Wizard enabled, both the microphone connector and the
headphones connector on the front of the PC can be retasked to perform a different
audio function. These two connectors are universal audio jacks. When you plug in a
cable, the wizard asks you to select the function for the cable from a list, and then it
sets the universal audio jack to perform as the selected function. The functions are:
• Stereo Speaker (Out)
• Microphone (In)
• Headphone (In)
• Audio Line In
To retask front-panel connectors:
1 Follow steps 1 through 7 of the procedure, “Using the Audio Wizard in the
Sound Effect Manager” on page 38.
2 When you plug in a cable, the wizard asks you to select the device you
plugged in from a list.
3 Close the window.
