Feature Index
See page
Grates, Drip Pans (on models so equipped) and Surface Burners
25,26
2 Oven Lamp On/Off Switch
I
13
3 Oven Control, Clock and Timer
10, 11
4 Oven Vents
4,5, 13,30
5 Cooktop
27
6 Surface Burner Controls
8
7 Broiler Pan and Rack
18,20,26
8 Oven Shelves (Easily removed or repositioned on shelf supports.)
12, 16,22,27
9 Oven Shelf Supports
I
12
10 Air Vent in Oven Door (Top of Oven Door.)
4,30
11 Storage Drawer
29
12 Air Intake (Under Storage Drawer.)
I
4,30
13 Model and Serial Numbers (On front frame
range, behind storage drawer.)
2,6,34
14 Removable Oven Door (Easily removed for oven cleaning.)
28
15 Anti-Tip Device (Lower right rear corner on range back.
3,33,40
See Installation Instructions.)
16 Oven Bottom
29,31,39
17 Oven Interior Light
30
18 Oven Door Latch (Use for Self-Cleaning cycle only.)
14, 18,20, 22–24
