HOW TO CONVERT THE RANGE FOR USE
WITH 1P GAS
OR
NATURAL GAS
TOOLS REQUIRED:
T-10 (for sealed burners)
1/2” and 3/4” open-end wrench
Flat blade screwdriver (small)
Nut drivers or wrenches: 7mm or 5/16”
(depending on the size of the spuds)
❑
PREPARE RANGE FOR CONVERSION
(1) Turn off gas supply at the wall.
(2) Turn off the electrical power to the range.
If range has not yet been connected to gas supply,
or if flexible connection was made, range maybe
pulled out from the wall to make conversion easier.
CONVERT THE PRESSURE REGULATOR
WARNING: Do not remove the pressure
regulator from the range.
1. For models equipped with sealed burners,
remove the storage drawer, broiler drawer or
kick panel and locate the pressure regulator at
rear of the range.
Remove Screws
Access Cover
On some models, you may have to remove an
access cover also.
For models equipped with dual burners, remove
the cooktop and locate the pressure regulator at
right rear of range.
❑
o Follow the directions in or B that
your regulator type.
e: On some models the
valve may be in a
different location.
If it is this regulator:
1. Use a coin to remove the cap from the
pressure regulator.
2. Turn the cap over and hook it into the slots.
The type of gas to be used should now be visible
on the top of the cap.
Note: On some models the shut-off valve
may be in a different location.
this protective cap Cap Assembly
except for conversion
If it is this regulator:
1. Unscrew the plastic-protected hex-nut cap
from the regulator.
2. Carefully pry the protective plastic cap off
the threaded metal cap. Gently pull the plastic
washer off the threads on the other side of the
metal cap.
3. Push the plastic cap onto the end of the metal
cap displaying the type of gas you are converting
to. Press the attached plastic washer onto the
threads on the other side of the metal cap.
4. Screw the hex-nut cap back into the regulator.
Do not overtighten.
41
