7
Installing the Anti-Scalp
Wheels
Parts needed for this procedure:
2 Anti-scalp wheels
2 Wheel bolt
2 Locknut
Procedure
Mount the anti-scalp wheels onto the wheel brackets
with the wheel bolts and locknut (Figure 9).
Figure 9
1. Wheel 3. Locknut
2. Wheel bracket 4. Wheel bolt
Note: Use the same hole height on both sides.
8
Preparing the Cutter Deck
Discharge Chute
No Parts Required
Procedure
1. Remove the roll pin from the discharge chute spring
and discard the pin.
Note: The roll pin is for shipment only
2. Ensure that the spring returns the discharge chute
to the full down position.
9
Lubricating the Tractor
No Parts Required
Procedure
Ensure that all of the necessary points on the tractor are
lubricated; refer to Greasing and Lubricating the Tractor
in Maintenance.
10
Checking the Safety Interlock
System
No Parts Required
Procedure
Check the safety interlock system; refer to Testing the
Safety Interlock System in Operation.
11
Purging the Hydro Transaxle
No Parts Required
Procedure
Shipping and handling can introduce air into the hydro
transaxle. For proper performance, remove all the
trapped air.
1. Move the tractor to a flat, level surface
2. Place the drive control in the Push position
(Figure 10).
