Top cover
NOTE: The top cover includes the TouchPad board and bracket.
Description Spare part number
Charcoal, for HP Mini 210 models 650747-001
Crimson Red, for HP Mini 210 models 650752-001
Glossy Black, for HP Mini 110 models 658512-001
Glossy Black, for Compaq Mini CQ10 models 663677-001
Luminous Rose, for HP Mini 210 models 650751-001
Ocean Drive, for HP Mini 210 models 650748-001
Pacific Blue, for HP Mini 110 models 658515-001
Sonoma Red, for HP Mini 110 models 658513-001
Sweet Purple, for HP Mini 210 models 654204-001
Before removing the top cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 44 ).
5. Remove the service door (see Service door on page 45 ).
6. Remove the keyboard (see Keyboard on page 53 ).
Remove the top cover:
1. Position the computer right-side up, with the front toward you.
2. Release the ZIF connector for the power button cable, and then disconnect the cable (1).
3. Release the ZIF connector for the speaker cable, and then disconnect the speaker cable (2).
56 Chapter 4 Removal and replacement procedures
