Storage
Options
6-61 Printer Options
1 Turn off the printer, and then disconnect the power cord and
all interface cables (parallel, serial, Ethernet, and optional)
and SCSI hard disk cables, if any, from the printer.
2 Access the printer controller board.
Use the instructions in the “Removing the Printer and Controller
Board Covers” section of this chapter.
3 Remove the screws securing the IDE-SCSI board to the rear
interface panel of the printer.
Save the screws. (You’ll use them when you reinstall the board.)
4 Remove the IDE-SCSI board from the plastic standoff and the
80-pin connector on the controller board.
To unlock the standoff, squeeze the tip between two fingers until
you can easily remove the board.
5 Install the internal hard disk.
n
If you’re installing an internal hard disk for the first time, use
the instructions in a following section, “Installing an Internal
Hard Disk.”
n If you’re removing an internal hard disk at this time (for exam-
ple, if you are removing an IDE hard disk to install a Kanji IDE
hard disk), use the instructions in a following section,
“Removing an Internal Hard Disk,” and then use the instruc-
tions in the “Installing an Internal Hard Disk” section.
Internal IDE Hard Disk
The internal IDE hard disk is identified as DSK7.
IDE Hard Disk Assembly Kit
The IDE hard disk assembly kit includes the following:
n IDE hard disk
n Plastic ribbon cable
n 4 screws
