Static Virtual LANs (VLANs)
Configuring VLANs
Fields that can be included in the customized display are shown in the table
below.
Field Display Example Default
id VLAN Id 5 6
name VLAN Name Vlan55 32
status Status Port-based 10
voice Voice enabled No 5
jumbo Jumbos enabled No 5
ipconfig How the ip address was configured Manual 10
Disabled
DHCP/BootP
ipaddr (IPv4) the IP address(es) 10.10.10.3 15 for IPv4
ipaddr (IPv6) fe80::212:79ff:fe8d:8000 46 for IPv6
ipmask The subnet mask(s) 255.255.255.6 15
/64 (prefix for IPv6 is in format “/XX”)
proxyarp Whether proxy arp is configured No 5
localproxyarp Whether local proxy arp is configured No 9
state “Up” if at least one port is up Up 5
The example in Figure 2-24 displays id at its default width, and will show up
to 20 characters of the VLAN name. The columns selected for display are
separated by spaces.
ProCurve(config)# show vlan custom A1-A3 id name:20 ipaddr state
Status and Counters - VLAN Information - Custom view
VLANID VLAN name IP Addr State
------ -------------------- --------------------------------- -----
1 DEFAULT_VLAN 15.255.134.74 Up
33 Vlan33 10.10.10.01 Up
44 Vlan44 15.255.164.13 Up
55 Vlan55 15.255.178.2 Down
15.255.178.3
15.255.178.4
60 Vlan60 fe80::212:79ff:fe8d:8000%vlan60 Up
Figure 2-24. Example of show vlan custom Command
If the width of the column requested is smaller than the header name of the
column, the display of the header name is truncated.
2-37
