Heat & Glo • Cyclone-Cust • 2061-900 Rev. L • 10/08

9

D. Mantel Projections

Figure 3.3 Clearances to mantels or other combustibles above appliance

SLIP

SECTION

COMBUSTIBLE

MATERIAL

41-3/8 in.

(+0 to -1/2 in.)

34-3/8 in.

TO CEILING

AND/OR MANTEL

FIRESTOP

FRAMING

MEMBER

GLASS

TUBE

TOP

OF UNIT
