Figure 5.5
1. Top Vent - Horizontal Termination - (continued)
Three Elbows
H
T
H
2
V
2
H
1
V
1
V
T
V
1
H
1
V
2
H
2
V
T
Min. H
T
Max.
* * * * 2 ft. 2 ft.
* * * * 3 ft. 6 ft.
* * * * 4 ft. 10 ft.
* * * * 5 ft. 15 ft.
V
T
+ H
T
= 40 ft. Max.
*No specifi c restrictions on this value EXCEPT
V
T
+ H
T
cannot exceed 40 ft. Max.
