Heat & Glo • Cyclone-Cust • 2061-900 Rev. L • 10/08 15
2. Top Vent - Vertical Termination
No Elbow
Figure 5.6
Figure 5.7
Two Elbows
CAP
V
T
V
2
V
1
V
T
H
T
V
T
MAX.
40 ft.
Drop the fl ue restrictor into the slip section as
shown.
SLIP
SECTION
FLUE
RESTRICTOR
GLASS
CYLINDER
ASSEMBLY
Flue Restrictor
Part No.
Inside
Diameter
Max. Vertical
(V
T
)
2061-204 2-3/4 in. 15-30 ft.
2061-203 2-1/2 in. 30 ft. or more
V
1
V
2
V
T
Min. H
T
Max.
* * 2 ft. 2 ft.
* * 3 ft. 6 ft.
* * 4 ft. 10 ft.
* * 5 ft. 15 ft.
V
T
+ H
T
= 40 ft. Max.
*No specifi c restrictions on this value EXCEPT
V
T
+ H
T
cannot exceed 40 ft. Max.
