Chapter 5 • Pointing the antenna
52
1035567-0001 Revision A
Final steps After pointing, make sure the required safety labels and/or signs
are present:
• Make sure a Radiation Hazard Caution label is present,
legible, and visible on the feed arm.
• If the antenna is enclosed by a fence, make sure a Radiation
Hazard Caution sign is present, legible, and visible on the
entrance gate.
• If the antenna is installed on a roof with a permanently
mounted access ladder, make sure a Radiation Hazard
Caution sign is present, legible, and visible on or near the
ladder.
Removing the fine elevation
pointing tool
Be sure to remove the fine elevation pointing tool so you can use
it for subsequent installations.
1. Remove the pointing tool’s upper and lower brackets from the
elevation bracket and canister.
2. Replace the nuts and bolts in the pointing tool’s tool brackets
so they will not get lost.
The antenna is now installed and pointed, ready for operation.
Refer to the IDU installation manual for information on how to
register and configure the site.
