Chapter 1 • Overview
2
1035567-0001 Revision A
Figure 1 shows the .74 m antenna installed on a pole mount.
Figure 1: Installed .74 m antenna
Radio (not visible)
in optional shroud
Antenna
reflector
Feed arm
Transmitter
Mast
