Chapter 4 • Cabling and connections
1035567-0001 Revision A
35
Ground connection
Figure 33 shows the location of the ground screw on the
transmitter. Ground the transmitter and mast. For grounding
procedures, refer to your training, best grounding practices, and
applicable parts of the NEC.
Figure 33: Ground screw on the transmitter
Ground
screw
Transmit
F connector,
female
Not used
