Hitachi Gigabit Router GR2000-B Series Quick Start Guide

2-12

GR2K-GA-0008

Rev. 1.00

2.9.3

Connecting a Setup Terminal to the GR2000-B

The RS

32C cable, across cable having the DUub 9-pin (female) on each end, is

required to connect the GR2000-B to a setup terminal. Connect the RS-232C cable
to the setup terminal in the same way as shown in Figure 2-15 below.

Figure 2-15 Connecting a Setup Terminal to the GR2000-B

2.9.4

Connecting the GR2000-B to Other Devices

Connect the GR2000-B to other devices by using interface cables. See the Figure 4-1
as an example.

*

Note: The required type of cables differs depending on an interface you use. For cable

specificationa and characteristics, see the GR2000-B Installation Guide.

RS-232C Cable

RS-232C Connector

(CONSOLE)

Setup Terminal

Connect the RS-232C cable to the router

Attach cable to the router firmly with screws

9-Pin D-Sub

Connector

Attachment

Screw

RS-232C Connector

(CONSOLE)
