Hitachi Gigabit Router GR2000-B Series Quick Start Guide
2-8 GR2K-GA-0008
Rev. 1.00
1. As shown in Figure 2-7, make sure that the power switch is depressed in the OFF
(0) position and plug the other end of the cable into the AC outlet you plan to use.
Figure 2-8 Location of Power Switch
2.7 Installing a Memory Card
This procedure shows the process for installing and removing a memory card from
memory card slot 0. The operations for the memory card slot 1 are same as those for
the memory card slot 0.
(1) Installing a Memory Card
1. Insert a memory card in the position shown in Figure 2-9 and Figure 2-10 below.
When successfully inserted the lever next to the slot will be pushed forward.
Figure 2-9 Installation of a Memory Card
*
Note: When inserting a memory card, the surface labeled with the part number
“HN-F9531-MC64X (BMC64)” should be face up.
Power Switch
ON
OFF
Memory Card
(Part number
should be face up) Memory Card
Slot
