Overview of Navigation and Controls
38
 Show message: The system will send message to the local host screen
to alarm you if you have enabled this function.
 Send email: The system can send out an email to alert you when the
alarm occurs.
 PTZ activation: Here you can set PTZ movement (of any video
channels) such as going to a preset when motion is detected in the
current video channel. Click Select, and you can see an interface is
shown as in
Figure 4-15 .
 Period: Click Set to determine the period for the channel to be armed
for motion detection. See the interface shown as in Figure 4-16 . Here
you can set for business days and non-business days. In Figure 4-16 ,
click Set, and you will see an interface as shown in Figure 4-17 . Here
you can set your own business day and non-business day.
 Alarm output: After the motion detection has occurred, the system
enables the peripheral alarm devices.
 Tour: Here you can enable the tour function when the alarm occurs. It
is a one-window tour. Please go to Display on page 74 for tour interval
setup.
Note
If there are record channels selected, only the record
channels will be displayed in the tour.
 Video Matrix: when the motion is detected, video will be displayed on
the monitor connected to the SPOT (matrix) output of the DVR.
Check boxes to select the corresponding function. After all the settings,
click Save, and the system will return to the previous menu.
Note
In Figure 4-14 , you can left click the mouse and drag it to
set a region for motion detection. Click Fn to switch
between arm/withdraw motion detection. After setting the
region, click the enter button to exit.
