Web Client Operation
122
Figure 6-38 Alarm Setup Menu
Please refer to the following sheet for detailed information.
Parameter Function
Event Type
It includes local alarm/network alarm.
Local alarm: Device detects alarm from input port.
Network: Device detects alarm from network.
Alarm in
Select corresponding alarm channel, and check the checkbox
beside it to enable system to detect alarm signal
Type
There are two options: normal open and normal close. NO
becomes activated in low voltage, NC becomes activated in
high voltage.
Period
Alarm record function becomes activated in the specified
periods.
There are six periods in one day. Please check the checkbox
to enable corresponding period.
Select date. If you do not, the current setup applies to today
only. You can select the all week column to apply it to the
whole week.
Click OK button, system goes back to alarm setup interface,
please click save button to exit.
Anti-dither Not effective in current DVR version.
Alarm Out
Enable alarm activation function. You need to select alarm
output port so that the system can activate corresponding
