115
Parameter Function
click Save.
Refresh
Click this button to get device latest configuration
information.
RS232
The RS232 interface is shown in Figure 6-32 .
Figure 6-32 RS232 Setup Menu
Please refer to the following sheet for detailed information.
Parameter Function
RS232 COM 01
Console is for debug and upgrade.
Function
Adapter is for system integration and function enhancement
Data Bit The value ranges from 5 to 8.
Stop Bit There are two options: 1/2.
Baud Bit You can select corresponding baud bit here.
