Rear oem trim modifications – Havis-Shields Kwik-Kit KK-100-03 User Manual
Page 3
KK-XXX-03_INST_10-07
3
Rear OEM Trim modifications
1997-2008 Chevrolet G-Series Van
Installation of Kwik Kit is very
similar in Ford and Chevy Vans.
All kits start with a
measurement at the rear floor.
The rear plastic floor trim on
Chevy vans must be cut straight
across as shown in photo.
Measure seven inches (7 1/4”)
from rear center of trim and cut
straight-line full width.
(Jig saw works well for this
step)
After plastic trim is cut and back in
it’s original location, you must
measure 7” inches forward on both
sides from newly cut trim to place
rear Kwik Kit bulkhead.
This is the starting position so parts
fit into the correct locations.
Note: With OEM rear AC/Heat,
The kit will be shifted to passenger
side.
.
*** Ford Van does NOT require
rear trim modification***
