Chapter 4
Peripherals and Accessories
4-108
HP e3000 Business Servers Configuration Guide – Effective 1/04
Information Subject to Change
Disk System Enclosure (DS2405) Hardware Ordering Information
Note: The DS2405 cannot be used with the VA7100.
The following codes define the suffixes on product numbers: A = Field Racked, AE = Empty enclosure (no
integration), AZ = Factory Racked.
Product
Number
Option Description
DS2405 Disk Enclosure Field Rack
A6250A
Disk System 2405 field rack enclosure (cables are not included and must be ordered separately)
A6250AE
Disk System 2405 field rack enclosure with no disk integration (cables are not included and must be ordered separately)
A6192A
36-GB 10K RPM Fibre Channel drive add-on
A6192A
0D1
36-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A6193A
36-GB 15K RPM Fibre Channel drive add-on
A6193A
0D1
36-GB 15K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A6194A
73-GB 10K RPM Fibre Channel drive add-on
A6194A
0D1
73-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A7288A
0D1
73-GB 15K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A7289A
0D1
146-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15, 7110 only)
DS2405 Disk Enclosure Factory Rack
A6250AZ
Disk System 2405 factory rack enclosure (cables are not included and must be ordered separately)
A6191A
0D1
18-GB 15K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A6192A
36-GB 10K RPM Fibre Channel drive add-on
A6192A
0D1
36-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A6193A
36-GB 15K RPM Fibre Channel drive add-on
A6193A
0D1
36-GB 15K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A6194A
73-GB 10K RPM Fibre Channel drive add-on
A6194A
0D1
73-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A7288A
0D1
73-GB 15K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15)
A7289A
0D1
146-GB 10K RPM Fibre Channel drive installed into the enclosure (must order minimum quantity 2, maximum = 15, 7110 only)
Disk Enclosure Upgrades
A6209A
System/E Rail Kit
A6496A
NTRittal Rack rail kit
A6244A
HP Original rack rackmount hardware kit
NOTES: A6183A requires rail kits to be ordered separately.
Cache memory for VAP ordering note: You must order one and only one cache memory option type for each array.
Fiber channel disk module ordering note: You must order at least two (2) but not more than fifteen (15) disk modules per enclosure. The unused slots must
contain a disk slot filler panel to insure proper cooling of the array. The factory will include filler panels for any remaining open drive bays.
DS2405 Disk System Accessories
C7524A
2-meter Fibre Channel cable LC 50/125 M/M
C7525A
16-meter Fibre Channel cable LC Duplex 50/125 M/M
C7526A
50-meter Fibre Channel cable LC Duplex 50/125 M/M
C7527A
200-meter Fibre Channel cable LC Duplex 50/125 M/M
C7529A
2-meter Fibre Channel cable LC/SC 50/125 M/M
C7530A
16-meter Fibre Channel cable LC/SC 50/125 M/M
C7540A
Fiber optic adapter kit
C7534A
Fiber optic coupler SC F/F
A6209A
System/E rack rail kit
A6244A
HP Original rack rackmount hardware kit
A6496A
NT/Rittal rack rail kit
A6498A
3U 2-post rail kit
