Chapter 4
Peripherals and Accessories
4-106 HP e3000 Business Servers Configuration Guide – Effective 1/04
Information Subject to Change
VA7410 Controller Enclosure Hardware Ordering Information
The following codes define the suffixes on product numbers: A = Field Racked, AE = Empty enclosure (no
integration), AZ = Factory Racked.
Order drives separately from the Enterprise Module section using the 0D1 option for integration. “AE”
products are shipped as diskless enclosure only no integration (disks are ordered separately and field
installed).
Product
Number Option Description
VA7410 Enterprise Field RK SKU
A6267A
VA7410 with Dual Controller 1024-MB Cache Includes: VA Enclosure, (2) 2-Gbps/1-Gbps VA Cont Module Assy, (1) DIMM
1,024-MB, User Guide, Installation Guide, Documentation Map, VA7x00 Documentation CD-ROM, (2) power cord, ESD Kit,
RS-232 cable 9-9 pin, HP Command View SDM. Field upgrade product. Select Virtual Array Controller (one or two) and
cache and disk options separately (factory installed). Field Installed. Includes enclosure assembly, user manual, and 2 power
supplies, filler panels for controllers and disks.
A6268A VA7410 with Dual Controller 2048-MB Cache Includes: VA Enclosure, (2) 2-Gbps/1-Gbps VA Cont Module Assy, (2) DIMM
1,024-MB, User Guide, Installation Guide, Documentation Map, VA7x00 Documentation CD-ROM, (2) power cord, ESD Kit,
RS-232 cable 9-9 pin, HP Command View SDM. Field upgrade product. Select Virtual Array Controller (one or two) and
cache and disk options separately (factory installed). Field Installed. Includes enclosure assembly, user manual, and 2 power
supplies, filler panels for controllers and disks.
A6187B 1 X 1024-MB Cache for Virtual Array Controller, 1 ×1024-MB DIMM, StorageWorks VAP requires equal cache for both
Controllers (if 2
nd installed). Order 1 per installed VAP
A6191A 0D1 Enterprise Class 18-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6192A 0D1 Enterprise Class 36-GB 10K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6193A 0D1 Enterprise Class 36-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6194A 0D1 Enterprise Class 73-GB 10K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A7288A 0D1 Enterprise Class 73-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed) (VA7110 and VA7410 only)
A7289A 0D1 Enterprise Class 146-GB 10K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed) (VA7110 and VA7410
only)
C7524A Fiber Optic Cable 2-meters LC 50/125 M/M
C7525A Fiber Optic Cable 16-meters LC Duplex 50/125 M/M
C7526A Fiber Optic Cable 50-meters LC Duplex 50/125 M/M
C7527A Fiber Optic Cable 200-meters LC Duplex 50/125 M/M
C7529A 2-meter FC fiber optic cable M/M duplex LC-SC
C7530A 16-meter FC fiber optic cable M/M duplex LC-SC
C7534A FC fiber optic coupler F/F SC-SC
C7540A FC adapter kit (includes C7529A and C7534A)
VA7410 Enterprise Factory Rack
A6267AZ
VA7410 with Dual Controller 1024-MB Cache Includes: VA Enclosure, (2) 2-Gbps/1-Gbps VA Cont Module Assy, (1) DIMM
512-MB, User Guide, Installation Guide, Documentation Map, VA7x00 Documentation CD-ROM, (2) power cord, ESD Kit, RS-
232 cable 9-9 pin, HP Command View SDM. Field upgrade product. Select Virtual Array Controller (one or two) and cache
and disk options separately (factory installed). Field Installed. Includes enclosure assembly, user manual, and 2 power
supplies, filler panels for controllers and disks.
A6268AZ VA7410 with Dual Controller 2048-MB Cache Includes: VA Enclosure, (2) 2-Gbps/1-Gbps VA Cont Module Assy, (2) DIMM
1024-MB, User Guide, Installation Guide, Documentation Map, VA7x00 Documentation CD-ROM, (2) power cord, ESD Kit,
RS-232 cable 9-9 pin, HP Command View SDM. Field upgrade product. Select Virtual Array Controller (one or two) and
cache and disk options separately (factory installed). Field Installed. Includes enclosure assembly, user manual, and 2 power
supplies, filler panels for controllers and disks.
A6187B 1 X 1024-MB Cache for Virtual Array Controller, 1 ×10242MB DIMM, StorageWorks VAP requires equal cache for both
Controllers (if 2
nd installed). Order 1 per installed VAP
A6191A 0D1 Enterprise Class 18-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6192A 0D1 Enterprise Class 36-GB 10K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6193A 0D1 Enterprise Class 36-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A6194A 0D1 Enterprise Class 36-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed)
A7288A 0D1 Enterprise Class 73-GB 15K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed) (VA7110 and VA7410 only)
A7289A 0D1 Enterprise Class 146-GB 10K RPM FC HDD (minimum of 10 drives per array - sizes may be mixed) (VA7110 and VA7410
only)
C7524A Fiber Optic Cable 2-meters LC 50/125 M/M
