Chapter 4
Peripherals and Accessories

4-104

HP e3000 Business Servers Configuration Guide – Effective 1/04

Information Subject to Change

VA7100 Rail Kits
The following rail kits are needed to mount the VA7100 into the specific racks as listed.

Part Number

Description

A6209A

System/E Rail Kit (RoseBowl 2)

A6496A

NTRittal Rack rail kit

A6244A

HP Original rack rackmount hardware kit

VA7110 Hardware Ordering Information

The following codes define the suffixes on product numbers: A = Field Racked, AE = diskless enclosure (field

disk integration), AZ = Factory Racked.

Order drives separately from the Enterprise Module section using the 0D1 option for integration. “AE”

products are shipped as diskless enclosure only no integration (disks are ordered separately and field

installed).

Product Number Option Number Description
VA7110 Field RK SKU
A7294A

Predefined SKU - VA7110 with Dual Controller, 2 GBICs, 1024-MB Cache (2×512MB DIMM)

A7296A

Predefined SKU - VA7110 with Dual Controller, 2 GBICs, 2048-MB Cache (2×1024MB DIMM)

A7293A

0D1

Field upgrade product. Select Virtual Array Controller (two) and cache (minimum 1024 MB) and disk options separately
(factory installed). Includes filler for controllers and disks. (Note that single controller configurations are not
supported!)

A6183AE

Empty

Enclosure

A7293A

0D1

Virtual Array Controller no memory installed (Note that single controller configurations are not supported!)

A6186A

0D1

1×512MB Cache for Virtual Array Controller, 1×512MB DIMM, StorageWorks VAP requires equal cache for both
Controllers (if two are installed). Order 1 per installed VAP

A6187B

0D1

1×1024MB Cache for Virtual Array Controller, 1×1024MB DIMM, StorageWorks VAP requires equal cache for both
Controllers (if two are installed). Order 1 per installed VAP

A6192A

0D1

36-GB 10K RPM FC HDD Module

A6193A

0D1

36-GB 15K RPM FC HDD Module

A6194A

0D1

73-GB 10K RPM FC HDD Module

A7288A

0D1

73-GB 15K RPM FC HDD Module

A7289A

0D1

146-GB 10K RPM FC HDD Module

C7524A

0D1

Fiber Optic Cable 2-meter LC 50/125 M/M

C7525A

0D1

Fiber Optic Cable 16-meter LC Duplex 50/125 M/M

C7526A

0D1

Fiber Optic Cable 50-meter LC Duplex 50/125 M/M

C7527A

0D1

Fiber Optic Cable 200-meter LC Duplex 50/125 M/M

C7529A

0D1

2-meter FC fiber optic cable M/M duplex LC-SC

C7530A

0D1

16-meter FC fiber optic cable M/M duplex LC-SC

C7534A

0D1

FC fiber optic coupler F/F SC-SC

C7540A

0D1

FC adapter kit (includes C7529A and C7534A)

VA7110 Factory Rack
A7294AZ
