Walkaround
The following illustrations identify the locations and names of key printer components.
1
2
3
4
5
6
7
8
Figure 1-1
Front view (shown with optional 500-sheet paper feeder)
1
Output bin extender
2
Output bin
3
Top cover
4
Printer control panel
5
Front door
6
Tray 1 (holds 100 sheets of standard paper)
7
Tray 2 (holds 250 sheets of standard paper)
8
Tray 3 (optional; holds 500 sheets of standard paper)
ENWW
Walkaround
7
