C Printer specifications
The printer specifications provide information about the size and weight, amount of power needed and
used, and noise output of the printer. The specifications also describe how the different operating modes
affect power consumption, heat output, and noise output.
Physical specifications
Table C-1 Physical dimensions for the HP Color LaserJet 3000, 3600, and 3800 Series printers
Product Height Depth Width Weight 1
Base model 400 mm (15.7 in) 450 mm (17.7 in) 400 mm (15.7 in)
20.3 kg
(44.8 lbs)
Base model plus duplexer 423 mm (16.7 in) 450 mm (17.7 in) 400 mm (15.7 in)
21.5 kg
(47.4 lbs)
Base model plus optional tray 3 540 mm (21.3 in) 450 mm (17.7 in) 400 mm (15.7 in) 25.4 kg (56 lbs)
Base model plus duplexer and optional
tray 3 563 mm (22.2 in) 450 mm (17.7 in) 400 mm (15.7 in) 26.6 kg
(58.6 lbs)
1 Printer weight does not include print cartridges.
